GENERAL DATA
| Model | JS3-1.8-130 |
| Voltage | 48 V |
| Power | 500 Watts |
| Max Flow Rate | 1.8 m³/h |
| Max Head | 130 m |
| Warranty | 12 Months |
| Outlet | 19mm (0.75 in) |
| Pump Diameter | 76 mm |
| Type of Pump | Screw |
| Submersible Depth | 30 m |
| Controller Input Voltage | 48V - 100V (VoC) |
| What's Included | Pump, Controller, Float Level Switches and 6m Cable |
Â
PACKED DIMENSIONSÂ
| Length | 610 mm |
| Width | 300 mm |
| Height | 150 mm |
| Weight | 12 kgs |
SOLAR PANEL REQUIREMENTS Â
| PANELS | VOLTAGE (VMP) | QTY |
| 340 Watts | 38.14V | 2 |
| 400 Watts | 41V |
